| Model |
CS-C7-R100-8G44WF |
| Camera |
| Resolution |
Dual 2K+ Resolution |
| Image sensor |
1/3" Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Fixed Lens |
2.8mm@F1.6 , view angle: 108°(Diagonal), 92° (Horizontal), 50°(Vertical) |
| PT Lens |
6mm@F1.6 , view angle: 60°(Diagonal), 51° (Horizontal), 28°(Vertical) |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto-switching |
| DNR |
3D DNR |
| WDR |
Digital WDR |
| Compression |
| Video Compression |
H.264/H.265 |
| Video/Audio Bit Rate |
Adaptive bit rate. |
| Image |
| Max. Resolution |
2560 × 1440 |
| Frame Rate |
Self-Adaptive during network transmission |
| Network |
| Smart Alarm |
Motion Detection, Human Shape Detection, Pet Detection, Patrol Mode Detection |
| Wi-Fi Pairing |
AP Pairing / Bluetooth Pairing |
| Protocol |
EZVIZ cloud proprietary protocol |
| Interface Protocol |
EZVIZ cloud proprietary protocol |
| Interface |
| Storage |
Micro SD card slot (Max. 512G) |
| Power |
Type-C |
| Wired Network |
RJ45 X 1 (10M/100M self-adaptive Ethernet port) |
| Wi-Fi |
| Standard |
IEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax |
| Frequency Range |
2.4GHz: 2.4 GHz ~ 2.4835 GHz5GHz: 5.150GHz~5.250GHz, 5.725 GHz ~ 5.850 GHz |
| Channel Bandwidth |
2.4GHz Supports 20MHz / 40MHz 5GHz Supports 80MHz |
| Security |
WPA-PSK, WPA2-PSK,WPA3-Personal |
| Transmission Rate |
2.4GHz Max. Rate Support: 11b_11M， 11g_54M， 11n_MCS7_20M， 11ax_MCS11_20M 5.15-5.25GHz Max. Rate Support: 11a_54M， 11n_MCS7_20-40M， 11ac_MCS9_20-40-80M， 11ax_MCS11_20-40-80M |
| Output Power (EIRP) |
20 dBm |
| Antenna Gain |
2.56dBi@2.48GHz， 3.18dBi@5.22GHz |
| General |
| Operating Conditions |
-20°C to 50°C (-4°F to 122 °F ), Humidity 95% or less (non-condensing) |
| Power Supply |
DC 5V/2A |
| Power Consumption |
8W max |
| IR Range |
MAX. 10 meters (33ft) |
| Dimensions |
100mm x 100mm x 98mm (3.94” x 3.94” x 3.86”) |
| Package Dimensions |
117mm x 117mm x 165mm (4.61” x 4.61” x 6.5”) |
| Net Weight |
310g |
| Bare Weight |
610g |
