| Model | RG-ES05 |
| Ports | 5 10/100M Base-T ports |
| Operating mode | Half-duplex, full-duplex, auto-negotiation mode |
| Support auto MDI/MDIX | |
| Backplane bandwidth | 1Gbps |
| Packet forwarding rate | 0.744Mpps |
| MAC address | 1K |
| Power supply | External, DC 5.0V / 600mA |
| Maximum power consumption | ≤2.5W |
| Fan | Fanless |
| Dimensions | 108.1mm*64mm*24.8mm |
| Temperature | Operating temperature: 0 ℃ ~ 40 ℃ |
| Storage temperature: -40 ℃ ~ 70 ℃ | |
| Humidity | Operating humidity: 10% ~ 90% RH |
| Storage humidity: 5% ~ 95% RH |
