| Model | RG-ES116G |
| Hardware specifications | |
| Ports | 16*10/100/1000 Mbps ports |
| Operating mode | Half-duplex, full-duplex, auto-negotiation mode |
| Support auto MDI/MDIX | |
| Switching capacity | 32Gbps |
| Package forwarding rate | 23.81Mpps |
| MAC address | 8K |
| Power supply | 100-240V AC |
| Port Mode | “Flow Control On”, “Flow Control Off”, “Port Isolation”, “Extend Data Transmission-10Mbps” from left to right |
| Power consumption | 11W |
| PoE | Not support |
| Fan | N/A |
| Dimensions (W x D x H) | 280 x 126 x 44mm |
| Operating temperature | 0℃ to 45℃ |
| Storage temperature | -40℃ to 70℃ |
| Operating humidity | 10% to 90% RH |
| Storage humidity | 5% to 95% RH |
